Vacuum Tribometer Overview
- 10-7 Torr vacuum
- mN to 200 N friction and down force
- Cryogenic cooling from -150°C
- Interchangeable tribology, hardness and scratch modules
- Up to 400°C (1000°C) temperature range
Vacuum Tribometer Features
The vacuum tribometer has several key design features that makes it the only commercial available tribometer to run a wide test conditions on same platform.
Patented force sensor
Capacitive sensors work across a high vacuum range with no drifts or degassing.
Cryogenic to high Temperature control
Close loop temperature controller. Up to -150°C nitrogen cryogenic cooling chamber. Standard 400°C or high power 1000°C heating chamber.
Close loop force control
Real-time close loop force control during the test. This allows to create automatic friction vs load and speed curves.
Quick to reach vacuum
Reach 10-7 torr vacuum in 45 minutes. Vacuum tribometer has integrated rough and turbo molecular pumps
Rotary and Linear modes
Rotary speed up to 5000 RPM, Linear speed up to 6 mm/s. Additional Piezo drives for precise motions.
Several Application Modules
Configeration allows to do scratch, indentation and tribology test on same platform.
Unmatched Load Cell Technology
The vacuum tribometer MVT-2 comes with patented multi dimension capacitive force sensor. The unique sensing technology provides unparalleled stability and resolution. The wide load range extends from mN to 200 N.
High resolution to detect minor difference in test
Negligible drifts over long runs and across wide test conditions
Caliberated to Traceable standards
Wide Test Range
Rtec vacuum tribometer comes in several application specific configurations.
Vacuum Tribology Test Data
Data shows coefficient of friction results from vacuum tribometer. The surface treatments were done on two samples.
Sample 1 – the plasma oxide treatment.
Sample 2 – silicon oxide treatment.
- 10 N force
- Velocity 4 mm/s
- Acceleration at 0.1 mm/s2.
- 10-6 Torr
Vacuum Tribology Solution
The vacuum tribometer is used extensively across a wide range of industries and applications:
